Cash Register With Barcode Scanner

Cash register with a barcode scanner

Which register scans, what it scans with, and what the pair costs

Four answers, then the combinations we have actually confirmed, each with one price. If yours is not one of them, that is a cable we will not guess at rather than a register that cannot scan.

Which registers can use a scanner?

Every current SAM4S register we sell except the entry-level ER-180U, whose manual documents no peripheral scanner port. Which scanner, and over which port, is the part that varies by model.

USB or serial?

The ER-260EJ, ER-265EJ, NR-510BE and NR-510RBE document a USB port for a scanner. The ER-900E and SPS-300 families are documented for RS-232 serial instead, so those take a serial reader and a serial cable chosen for the exact port.

Do I need 1D or 2D?

Ordinary shop barcodes are 1D. A 2D reader also reads codes such as QR and Data Matrix. Either way the register stores the same kind of item record, so 2D changes what you can read, not what the register can do with it.

Does it have to be programmed?

Yes, on both sides: setup barcodes on the reader, and the register’s port set to scanner mode. Standard programming and setup are included with this register.

Choose a package from $772.75 Compare every register Get help choosing Programming and setup

Register and scanner, ready to ring

Each pair below is recorded in our catalogue as a confirmed scanner combination, down to the exact scanner configuration. The total is the register plus that scanner, and standard programming and setup come with the register.

ER-260EJ cash register TS100 barcode scanner

Small retail counter

ER-260EJ with a USB presentation scanner

  • ConnectionUSB
  • Reads1D and 2D
  • ItemsUp to 3,200 PLUs in internal memory; up to 8,000 with SD card storage

Power: Bus powered over USB

Package$772.75

Ask us to confirm it

NR-510RBE cash register TS100 barcode scanner

Convenience and liquor

NR-510RBE with a USB presentation scanner

  • ConnectionUSB
  • Reads1D and 2D
  • ItemsOver 3,200 PLUs (8,000 with SD card)

Power: Bus powered over USB

Package$888.75

Ask us to confirm it

ER-925E cash register TS100 barcode scanner

Busy retail counter

ER-925E with a serial presentation scanner

  • ConnectionRS-232 serial
  • Reads1D and 2D
  • ItemsUp to 22,000 PLUs

Power: Included in the serial configuration; an RS232 port supplies no bus power

Package$1,022.75

Ask us to confirm it

SPS-345 cash register TS100 barcode scanner

Larger item file

SPS-345 with a serial presentation scanner

  • ConnectionRS-232 serial
  • Reads1D and 2D
  • ItemsOver 19,000 PLUs

Power: Included in the serial configuration; an RS232 port supplies no bus power

Package$1,102.75

Ask us to confirm it

Flat-keyboard registers scan too. Their documented route is a Code reader over RS-232, and the manufacturer guide publishes no cable part number, so we confirm the cable for your exact port before the order ships rather than listing a fixed package. Tell us the model and we will price it the same day.

Every current register

Which register, and which scanner goes with it

Item capacity, keyboard, printing and payments come from each register's own record, so this table says exactly what the model's own page says. Sorted by price.

Current SAM4S cash registers compared by best use, item capacity, documented scanner support, the scanner we pair with each one, what that scanner reads, connection type, keyboard, printing, card payments and price
Register Best for Items Scanner We pair it with Reads Connection Keyboard Printing Payments Price
ER-180U Small Business and Service 500 open or preset Price Look-Ups (PLUs) Not documented — — Ask us Raised keys Receipt Separate terminal $279View ER-180U
ER-265EJ Food Service, Small Business and Service Up to 3,200 PLUs in internal memory; up to 8,000 with SD card storage Documented Confirmed per order — USB Flat keys Receipt Integrated option $599View ER-265EJ
ER-260EJ Retail, Small Business and Service Up to 3,200 PLUs in internal memory; up to 8,000 with SD card storage Documented TS100 1D and 2D USB Raised keys Receipt Integrated option $599View ER-260EJ
NR-510BE Food Service Over 3,200 PLUs (8,000 with SD card) Documented Confirmed per order — USB Flat keys Receipt Integrated option $679View NR-510BE
NR-510RBE Retail, Liquor Store, Convenience Store Over 3,200 PLUs (8,000 with SD card) Documented TS100 1D and 2D USB Raised keys Receipt Integrated option $715View NR-510RBE
ER-920E Food Service Up to 22,000 PLUs Documented Confirmed per order — RS-232 serial Flat keys Receipt Integrated option $815View ER-920E
ER-925E Retail, Liquor Store, Convenience Store, Grocery Up to 22,000 PLUs Documented TS100 1D and 2D RS-232 serial Raised keys Receipt Integrated option $849View ER-925E
ER-915E Retail, Liquor Store, Convenience Store, Grocery Up to 22,000 PLUs Documented TS100 1D and 2D RS-232 serial Raised keys Receipt + journal Integrated option $849View ER-915E
ER-940E Food Service Up to 22,000 PLUs Documented Confirmed per order — RS-232 serial Flat keys Receipt + journal Integrated option $879View ER-940E
SPS-320 Food Service Over 19,000 PLUs Documented Confirmed per order — RS-232 serial Flat keys Receipt Confirm first $879View SPS-320
ER-945E Retail, Liquor Store, Convenience Store, Grocery Up to 22,000 PLUs Documented TS100 1D and 2D RS-232 serial Raised keys Receipt + journal Integrated option $899View ER-945E
SPS-340 Retail, Food Service Over 19,000 PLUs Documented Confirmed per order — RS-232 serial Flat keys Receipt + journal Confirm first $915View SPS-340
SPS-345 Retail, Liquor Store, Convenience Store, Grocery Over 19,000 PLUs Documented TS100 1D and 2D RS-232 serial Raised keys Receipt + journal Confirm first $929View SPS-345
SAP-630II-RT Ask us Ask us Documented CR950 1D and 2D USB Raised keys See details Integrated via SAM4POS $1,999View SAP-630II-RT
SAP-630II-FT Ask us Ask us Documented CR950 1D and 2D USB Flat keys See details Integrated via SAM4POS $1,999View SAP-630II-FT

"Documented" means the pairing is recorded, not that it is plug-and-play: the port still has to be set to scanner mode and the reader still has to be programmed. Where a column reads "Confirmed per order", the register scans but the exact reader and cable are settled with you before the order ships.

1D or 2D?

1D The ordinary retail barcode: UPC and EAN, the striped label on packaged goods. This is what most shops scan all day.
2D Adds square codes such as QR and Data Matrix, where the scanner supports them. Useful if you also handle coupons, loyalty codes or labels printed as 2D.

Keep the two halves separate. The scanner decides which symbols can be read. The register decides what can be stored against them, and that is the item file, the price levels and the reports on the model’s own page. A 2D reader does not give a cash register any capability it did not already have.

How a scanner reaches the register

Every scan follows the same four steps. What differs between families is the middle one.

Barcode, then scanner, then cash register, then the item and price appear on the receipt Barcode Scanner Cash register Receipt on the item reads the code looks up the item item and price
  • USB route ER-260EJ, ER-265EJ, NR-510BE, NR-510RBE. The scanner plugs into the register’s USB port and draws its power from it. No separate power supply.
  • RS-232 serial route ER-915E, ER-920E, ER-925E, ER-940E, ER-945E, SPS-320, SPS-340, SPS-345. The scanner connects to a serial port that has to be set to scanner mode, and the cable has to match that exact port — on the ER-900E, COM 1 and 2 are DB-9 while COM 3 and 4 are RJ-45 on the same machine. Serial ports supply limited power, so a serial reader is supplied with its own.

The manufacturer setup guide publishes no cable part number, so we will not sell you one blind. Tell us the register model and the port you intend to use and we confirm the cable before anything ships.

What we check before selling you a combination

  • The exact register model, because ports differ inside the same family
  • The available interface, and the cable that actually fits it
  • Scanner-side configuration
  • The barcode symbologies your stock uses
  • Item-file and PLU capacity
  • Power draw, where several serial devices share one supply

Tell us the register and the scanner and we will say which parts are confirmed and which we need to check — before anything is charged. Ask us to check a combination

Which setup for which shop

Each register records the kinds of business it is listed for. These are those listings, showing only models whose scanner support is documented, cheapest first. What usually decides between them is how many items you carry and whether you want a printed journal as well as a receipt.

Retail

Item-driven checkout for general retail operations.

  • ER-260EJ Up to 3,200 PLUs in internal memory; up to 8,000 with SD card storage · $599
  • NR-510RBE Over 3,200 PLUs (8,000 with SD card) · $715
  • ER-925E Up to 22,000 PLUs · $849

Convenience Store

Fast item-driven checkout for convenience retail.

  • NR-510RBE Over 3,200 PLUs (8,000 with SD card) · $715
  • ER-925E Up to 22,000 PLUs · $849
  • ER-915E Up to 22,000 PLUs · $849

Liquor Store

Barcode-heavy retail checkout for liquor and beverage stores.

  • NR-510RBE Over 3,200 PLUs (8,000 with SD card) · $715
  • ER-925E Up to 22,000 PLUs · $849
  • ER-915E Up to 22,000 PLUs · $849

Grocery

Barcode-heavy item checkout for grocery and market operations.

Food Service

Menu-driven checkout for restaurants, counters, cafés, and similar food operations.

  • ER-265EJ Up to 3,200 PLUs in internal memory; up to 8,000 with SD card storage · $599
  • NR-510BE Over 3,200 PLUs (8,000 with SD card) · $679
  • ER-920E Up to 22,000 PLUs · $815

Small Business and Service

Straightforward checkout for small retail, service counters, and similar operations.

  • ER-265EJ Up to 3,200 PLUs in internal memory; up to 8,000 with SD card storage · $599
  • ER-260EJ Up to 3,200 PLUs in internal memory; up to 8,000 with SD card storage · $599

Gift shops, hardware stores, pet shops, small general stores and other specialty retail are item-driven retail: start from the retail group and let your item count decide the model. If you sell anything by weight, tell us the scale before you order, because a scale has to match the register as carefully as a scanner does.

Scanners we stock

The scanners, and what is actually known about each one

Every scanner here is in stock and priced. What differs is how much we can tell you about your register before you buy, so each one says which it is rather than carrying the same badge.

Check compatibility

Prices are for the scanner kit only. A scanner almost always needs programming on both sides: setup barcodes on the reader, and the register's port set to scanner mode.

Compatibility status

What is actually verified, scanner by scanner

Two things are easy to confuse. A manufacturer datasheet tells you what a scanner is. It does not tell you that it works with a SAM4S register, and that is the part that decides whether your morning goes well.

Unitech MS836 1D Laser Barcode Scanner – USB with Stand Interface unconfirmed

Register compatibility verification required.

Code CR950 1D/2D Barcode Scanner – SAM4POS USB

    Unitech TS100 1D/2D Barcode Scanner – USB or Serial/RS232 for Cash Registers USB

      Code CR5215 Barcode Scanner – USB USB

      Code CR5215 Barcode Scanner – Serial with Power Supply RS-232 serial

      Code CR950 1D/2D Barcode Scanner – USB USB

      Code CR950 1D/2D Barcode Scanner – Serial with Power Supply RS-232 serial

      Code CR950 1D/2D Barcode Scanner – Serial, No Power Supply RS-232 serial

        Zebra LS2208 1D Barcode Scanner, with USB Cable and Stand USB

        Register compatibility verification required.

        Zebra DS4608-SR 2D USB Barcode Scanner Kit with Cable and Stand USB

        Register compatibility verification required.

        Zebra DS2208-SR 2D USB Barcode Scanner Kit with Cable and Stand USB

        Register compatibility verification required.

        Honeywell Voyager XP 1470g Barcode Scanner Kit – 2D USB Scanner with Stand USB

        Register compatibility verification required.

        Honeywell Voyager 1250g 1D Barcode Scanner Kit – USB with Stand USB

        Register compatibility verification required.

        Datalogic Magellan 1500i 2D Presentation Barcode Scanner, Black USB

        Register compatibility verification required.

        A register listed here means the pairing is documented, not that it is plug-and-play. Port programming, baud settings and the correct cable still have to be right.

        Not sure which scanner works with your register? Send us the register model and we will tell you which of these fits, what cable it needs, and what has to be programmed, before you spend anything.

        Check compatibility

        Build the whole counter

        Work out the register and the scanner together

        The scanner question only has a real answer once we know the register. A few steps, and you will get either a package you can buy or a short list of what we need to confirm.

        What this asks you

        1. Your business type — retail, food service, liquor, convenience, grocery or a service counter. It decides which registers are worth showing.
        2. The register — raised-key suits item and barcode entry; flat keyboards suit menu-driven ordering.
        3. Barcode scanning — including whether you already own a scanner we should check.
        4. Printing — the receipt printer, the second built-in station, an external receipt printer and a kitchen printer are four different things, and only the last one prints in a prep area.
        5. Other peripherals — a cash drawer is already included with every current register we sell, so it is listed, not sold to you again.
        6. Programming — departments, items, taxes, clerks, tenders and menu keys, quoted before any work starts.
        7. Card processing — optional. You do not need to change processors to buy a register from us.

        At the end you get one of three answers: a package you can buy, a package to configure, or verification required — which means one part of the combination is not proven yet and we will confirm it before you spend anything. We would rather tell you that than sell you a scanner that turns out not to talk to your register.

        Talk to a specialist Review what I pay for processing

        Asked before every scanner order

        Cash registers and barcode scanners, answered

        Which SAM4S cash registers work with a barcode scanner?

        All of the current models we sell except the entry-level ER-180U. The ER-260EJ, ER-265EJ, NR-510BE and NR-510RBE document a USB port for a scanner. The ER-915E, ER-920E, ER-925E, ER-940E, ER-945E, SPS-320, SPS-340 and SPS-345 are documented for RS-232 serial peripheral connections instead. The ER-180U documents no peripheral scanner port, so it is the one register we will not sell with a scanner.

        Which scanner should I buy for my register?

        Match the interface first. A USB register takes a USB reader and powers it from the port; a serial register takes an RS-232 reader with its own power supply and a cable chosen for the exact port. The comparison table on this page names the scanner we pair with each register where our catalogue records a confirmed combination, and says “confirmed per order” where the reader and cable are settled with you before the order ships.

        Should I buy a 1D or a 2D barcode scanner?

        1D covers the ordinary retail barcode, UPC and EAN, which is what most shops scan all day. 2D adds square codes such as QR and Data Matrix. Buy 2D if you also handle coupons, loyalty codes or labels printed as 2D. The register stores the same kind of item record either way, so 2D changes what can be read, not what the register can do with it.

        How does a barcode scanner connect to a cash register?

        Either into a USB port or into an RS-232 serial port, depending on the model. Serial is the part that catches people out: on the ER-900E family, COM 1 and COM 2 present a DB-9 connector while COM 3 and COM 4 present RJ-45 on the same machine, and the manufacturer’s scanner cable diagram uses the RJ-45 route with a crossover. A standard DB-9 serial scanner cable will not fit the port the guide tells you to use. No cable part number is published, so we confirm the cable for your register and port before anything ships.

        How many barcoded products can a cash register hold?

        It varies widely by model, from 500 items on the ER-180U to 8,000 on the ER-260EJ and ER-265EJ, over 19,000 on the SPS-300 models and up to 22,000 on the ER-900E models. Those are the figures published for each register and the ones in the table above. Capacity is shared with other memory areas on some models, so treat the headline number as the qualifying figure rather than a guarantee about one specific configuration.

        Does barcode scanning need programming?

        Yes, on both sides. The reader is configured with the manufacturer’s setup barcodes for a SAM4S register, and the register’s port is set to scanner mode with matching communication settings. Then each barcoded item needs a record in the register: the barcode number, a description, a price and its department and tax assignment. Scanning an item the register does not hold will not ring it up.

        Can you program the register before it ships?

        Yes. Standard programming and setup are included with this register. Tax, departments, items, prices, clerks, keyboard layout and receipt details are set up with your register. Custom work beyond the standard setup is quoted separately. Send the item list in whatever form you have it, with the barcode, description, price and the department or tax each item belongs to. The included 90 days of support afterwards covers normal operation and correcting the programming we supplied; it is not unlimited data entry or unlimited reprogramming, so a large or ongoing item build is quoted rather than assumed.

        Can a register with a scanner also take card payments?

        On most of these models, yes, and it is a separate decision from the scanner. Integrated processing sends the sale total from the register to the card terminal, and the comparison table shows which models offer it and which we confirm first. You can also buy any register here and keep your current processor and terminal.

        What does a complete cash register and barcode scanner package cost?

        The packages at the top of this page show the current total for each confirmed combination: the register, the scanner in the exact configuration that fits it, and standard programming and setup included. Prices there are live, so what you see is what it costs today.

        Can I use the barcode scanner I already have?

        Often, yes. Send the make and model, how it connects and a photo of the plug, along with your register model. We will tell you whether it can be programmed to work, what cable it needs, and whether anything has to change — before you spend anything.

        Do I need a cash register or a POS system for barcode scanning?

        A cash register scans, looks up the item and prints a receipt, and it does that without an internet connection. A POS system adds screen-based ordering, deeper inventory and reporting, and staff and customer records. If scanning and a solid item file is the whole requirement, a register is usually the cheaper and simpler answer.
