CAS BW Series Bench Scale
Regular price
$745.00 USD
Description
CAS BW Series Bench Scale
Choose and configure your scale
CAS BW Series Bench Scale: fit, connections & ordering
Check your counter fit
Bench/platform scale with raised tilt-and-swivel indicator, serial interface and 150 lb or 300 lb capacity. The DB item numbers are explicitly mapped in the CAS catalog.
- Exact item mapping
- BW-60DB = BW-60, 150 × 0.05 lb; BW-150DB = BW-150, 300 × 0.1 lb. Direct model/item table, not inferred from SKU. CAS source, p. 31
- kg capacity/readability
- BW-60: 60 × 0.02 kg; BW-150: 150 × 0.05 kg CAS source, p. 2
- Interface
- RS-232C CAS source, p. 2
- Power
- Six C cells (9 V total) or DC 12 V 850 mA adapter CAS source, p. 2
- Dimensions/platter (catalog)
- Manufacturer reference: 16.7 × 26.2 × 29.7 in; platform 15.6 × 20.6 in. Confirm the exact supplied configuration and revision. CAS source, p. 31
- Features
- Tilt 90° / swivel 360° indicator; checkweighing and counting (counting not legal for trade); platform environmentally sealed to IP65 standards; 0.92 in LCD CAS source, p. 2
Manufacturer documentation
- BW Series Owner's Manual — match the exact model and revision.
Options to verify
- Wall mount kit. Confirm the exact accessory model, fit and required connections before ordering. Manufacturer/supplier reference.
- DEP-50 receipt printer. Confirm the exact accessory model, fit and required connections before ordering. Manufacturer/supplier reference.
- RS-232C cable. Confirm the exact accessory model, fit and required connections before ordering. Manufacturer/supplier reference.
Will this connect to my register or software?
Confirm the exact host model, software or firmware version, communication protocol and cable before ordering. An interface alone does not establish compatibility.
Which capacity should I choose?
BW-60DB is the 150 lb model; BW-150DB is the 300 lb model.
Before you order
Match the capacity to your heaviest item and container, then check resolution and space. Use the product options above to choose the exact configuration and see its current price and purchase controls.
Allow space for the whole scale and display, not only the weighing platform. If you need printed output or data transfer, confirm the exact printer, host software, interface and cable; a serial port alone does not establish a supported system.
Ask us to verify this configurationCompare scale types in the existing buying guide · Scale accessories
| Option | SKU |
|---|---|
| 150 lb | BW-60DB |
| 300 lb | BW-150DB |
Questions about CAS BW Series Bench Scale
Which configuration should I choose?
Start with your maximum item weight and required resolution. Then confirm the display position, counter dimensions and any interface or label requirements. The table above lists the configurations currently offered for this model.
Does a photograph establish the exact configuration?
Photographs illustrate the model family. Confirm capacity, display position, platform dimensions and included options against the configuration selected before ordering.
Where can I find the manual?
Use the manufacturer document links in the specifications above. Match the document to your exact model and revision before changing settings.
Complete your system
Take card payments through the same system
Integrated payments mean the card terminal and the register talk to each other, so the sale is entered once and the totals agree at the end of the day.
One setup, one support call
The register, the peripherals and the payment side are set up together, so when something needs attention there is one number to ring.
Checked against each other first
We verify the register, the processing program and the integration path as one combination before recommending it, rather than assuming parts fit.
A processor change is not required to buy equipment. If you are already taking cards, send us a recent statement and we will tell you plainly whether a change is worth making.
Current product
Current
Options
Descriptions
The CAS BW Series is a legal-for-trade bench/platform scale for warehouses, shipping and receiving, farmers markets and other commercial environments that need a larger platform and a raised indicator.
Key features
- BW-60DB: 150 lb × 0.05 lb. BW-150DB: 300 lb × 0.1 lb.
- 1 in LCD with backlight
- The weighing platform is environmentally sealed to IP65 standards.
- Standard RS-232 interface
- Switchable kg / lb operation
- AC adapter included
- Can operate on six C-cell batteries
- Optional printer support
- NTEP approved: COC #98-085
Overall scale size: 16.7 in W × 26.2 in D × 29.7 in H. Platform: 15.6 in W × 20.6 in D.
